The prong length should be a minimum of 75% of the roll length.
| Model | Model Description | Working Load Limit (WLL) kg | Load Centre (mm) | Mounting Class | Prong Diameter (mm) | Prong Length (mm) |
|---|---|---|---|---|---|---|
| Model: RPC-QR2-40-1200 | Model Description: Class 2 - 40?? x 1.2m | Working Load Limit (WLL) kg: 200 | Load Centre (mm): 600 | Mounting Class: Class 2 | Prong Diameter (mm): 40 | Prong Length (mm): 1200 |
| Model: RPC-QR2-50-1800 | Model Description: Class 2 - 50?? x 1.8m | Working Load Limit (WLL) kg: 250 | Load Centre (mm): 900 | Mounting Class: Class 2 | Prong Diameter (mm): 50 | Prong Length (mm): 1800 |
| Model: RPC-QR2-60-2800 | Model Description: Class 2 - 60?? x 2.8m | Working Load Limit (WLL) kg: 340 | Load Centre (mm): 1400 | Mounting Class: Class 2 | Prong Diameter (mm): 60 | Prong Length (mm): 2800 |
| Model: RPC-QR2-70-2800 | Model Description: Class 2 - 70?? x 2.8m | Working Load Limit (WLL) kg: 510 | Load Centre (mm): 1400 | Mounting Class: Class 2 | Prong Diameter (mm): 70 | Prong Length (mm): 2800 |
| Model: RPC-QR2-80-2800 | Model Description: Class 2 - 80?? x 2.8m | Working Load Limit (WLL) kg: 850 | Load Centre (mm): 1400 | Mounting Class: Class 2 | Prong Diameter (mm): 80 | Prong Length (mm): 2800 |
| Model: RPC-QR3-70-2700 | Model Description: Class 3 - 70?? x 2.7m | Working Load Limit (WLL) kg: 530 | Load Centre (mm): 1350 | Mounting Class: Class 3 | Prong Diameter (mm): 70 | Prong Length (mm): 2700 |
| Model: RPC-QR3-80-2700 | Model Description: Class 3 - 80?? x 2.7m | Working Load Limit (WLL) kg: 890 | Load Centre (mm): 1350 | Mounting Class: Class 3 | Prong Diameter (mm): 80 | Prong Length (mm): 2700 |
| Model: RPC-QR3-100-2800 | Model Description: Class 3 - 100?? x 2.8m | Working Load Limit (WLL) kg: 1700 | Load Centre (mm): 1400 | Mounting Class: Class 3 | Prong Diameter (mm): 100 | Prong Length (mm): 2800 |
Have a question about this product?
For detailed specifications please complete the form below and our sales team will be in touch shortly.
If the right piece of equipment isn’t available off the shelf, our in-house team can design, certify and build it for you. From tailored variations of standard products to full custom builds, we work closely with you to deliver safe, reliable solutions that meet the unique demands of your business.
